Description
1N5711 RF Schottky Diode 70V 15mA 0.43W DO-35 High-Speed Signal Detector Diode (Low Power RF/Logic – Not a Power Rectifier like 1N5819)
The 1N5711 from STMicroelectronics is a high-speed RF Schottky diode designed for low-level signal detection, switching, mixing, and high-frequency applications. Unlike power rectifier diodes such as the 1N5819, this part is optimized for very low current operation and fast response times, making it ideal for RF circuits, radio equipment, instrumentation, and signal processing applications where speed and low capacitance matter more than current capacity.
This diode is commonly used in RF detectors, mixers, demodulators, clamp circuits, and high-speed switching networks. Because of its extremely low forward current rating, it should NOT be used in power supply rectification or high-current applications.
- RF Schottky diode (low capacitance, high-speed switching)
- 70V peak reverse voltage rating
- 15mA maximum current (signal-level operation only)
- 0.43W power dissipation
- DO-35 through-hole axial glass package
- Very low junction capacitance (~2pF)
- Designed for RF detection, mixing, and signal processing
- Fast switching performance for high-frequency circuits
- Obsolete part status (limited availability depending on supplier)
- Manufacturer: STMicroelectronics
- Manufacturer Part Number: 1N5711
⚠️ Important: This is a low-current RF diode and is NOT interchangeable with power Schottky diodes such as the 1N5819 (1A power rectifier used in power supplies and reverse polarity protection).
